AED 19,602
* Prices are inclusive of VAT
This product is out of stock, but you can request a quote to be notified when it’s available.
A revolution in authentic analog sound, control and behavior, the AN-X engine recreates the warm, classic sound of an analog synthesizer with a host of sophisticated modulation options. ･Three Oscillators with 5 waveforms (Saw 1, Saw2, Triangle, Square and Sine) and Noise Generator
Experience realism and detail with MONTAGE M’s improved AWM2. Offering an incredible 128 Elements per part, AWM2 allows for smoother transitions, giving you an expansive canvas for ultra-high-definition sound creation, especially for “nameable” sounds such as piano and strings.
The MONTAGE M represents a significant upgrade from the original MONTAGE's 256 notes, offering a massive total of up to 400 notes of polyphony distributed across its three synthesis engines. Specifically, it provides 128 notes for AWM2 Preset Waveform Parts, an additional 128 notes for AWM2 User Waveform Parts, 128 notes for FM-X Parts, and 16 notes for the new AN-X Parts, ensuring deep and complex sound design without voice stealing.
MONTAGE M offers twice the memory over its predecessor with an increase from 5.67GB to 9.97GB of Preset Wave memory, and an increase from 1.75 to 3.8GB of User flash memory. Plus, you’ll find a host of new sounds and instruments, including pianos, orchestral instruments, drums, and more!
| Category | Specification |
|---|---|
| Size / Weight | |
| Dimensions (W × H × D) | 1,037 × 131 × 396 mm (40-13/16″ × 5-3/16″ × 15-9/16″) |
| Weight | 15.3 kg (33 lbs., 12 oz.) |
| Packing Box (W × H × D) | 1,223 × 259 × 482 mm (48-1/8″ × 10-3/16″ × 19″) |
| Control Interface | |
| Keyboard | 61 Keys, FSX Keyboard, Initial Touch: Yes, Aftertouch: Channel After Touch |
| Tone Generator | |
| Engine | Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise |
| Maximum Polyphony | AWM2: 256, FM-X: 128, AN-X: 16 |
| Multi Timbral Capacity | 16 Parts (internal), Audio Input Parts (A/D1, USB1) |
| Wave Memory | Preset: 10 GB, User: 3.7 GB |
| Performance Presets | 3,369 |
| Filter | 18 types |
| Effects | Reverb x 12, Variation x 88, Insertion A x 88, Insertion B x 89, Master Effect x 26, Master EQ: 5 bands, 1st Part EQ: 3 bands, 2nd Part EQ: 2 bands |
| Other Controllers | Master Volume, A/D Input Gain, Pitch Bend Wheel, Modulation Wheel, Ribbon Controller, Control Slider x 8, Knob x 8, Super Knob, Display Knob x 6, Portamento Knob, Data Dial, Assignable Switch x 2, MSEQ Trigger Switch, Portamento Switch, Keyboard Hold Switch, Ribbon Controller Hold Switch |
| Display | 7″ TFT Color Wide VGA LCD, 512 x 64 Full-dot LCD |
| Connectors | USB TO DEVICE x 2, USB TO HOST, MIDI IN/OUT/THRU, Foot Controller 1/2, Foot Switch (Sustain/Assignable), Output (Balanced) L/MONO, R, Assignable Output L/R, Phones 6.3 mm, A/D Input L/R 6.3 mm |
| Power Consumption | 36 W |
| Accessories | AC Power Cord, Quick Guide, Cubase AI Download Info, Expanded Softsynth Plugin for MONTAGE M Download Info |
| Live Sets | Preset: 128+, User: 2,048 |
| Performance Recorder | |
| Note Capacity | 1 Song/Pattern: 130,000 notes, Store Area: 520,000 notes (Pattern & Song) |
| Note Resolution | 480 ppq |
| Tempo (BPM) | 5 – 300 |
| Sequence Formats | MONTAGE Original, SMF 0/1 |
| Arpeggio | Parts: 8 simultaneous, Preset: 10,922+, User: 256 |
| Sequencer | |
| Patterns | 128 |
| Pattern Tracks | 16 Sequence Tracks |
| Pattern Recording Type | Real-time Replace, Real-time Overdub |
| Songs | 128 |
| Song Tracks | 16 Sequence Tracks, Tempo Track, Scene Track |
| Song Recording Type | Real-time Replace, Real-time Overdub, Real-time Punch In/Out |
| Functions | USB Audio Interface: Input: 6 channels (3 stereo) @ 44.1 kHz – 192 kHz, Output: 32 channels (16 stereo) @ 44.1 kHz, 8 channels (4 stereo) @ 44.1 kHz – 192 kHz |
